You can mount the keypad
with the potentiometer for a
NEMA1 rated installation.
The kit also provides for
removing the potentiometer
knob to meet NEMA 4X
requirements,as shown
(part no.4X-KITmini).
Additional operation using optional operator WOP
Main Features for WOP (SJ700D only)
-Large 5-line LCD screen
-Real time clock
-Copy function: Storing 4 sets of parameter settings
-Selectable display mode
4X-KITmini (For installation with OPE-SR mini)
Panel
Screw
External
Gasket
Front
Cover
Internal
Gasket 1
Internal
Gasket 2
Rear Cover
Cable
Cable <ICS-1,3>
L
Operator, Cable
Operator
Model
OPE-SR mini
OPE-SBK
OPE-SR
WOP
SRW-0EX
*1
Potentiometer
Model
ICS-1
ICS-3
Cable Length
1m (3.3ft)
3m (9.8ft)
Remote Control Copy function
Applied Model for Built-in
SJ200
Standard for SJ700/SJ700D,SJ700B
SJ700/SJ700D,SJ700B
SJ700/SJ700D,SJ700B,SJ300,L300P
SJ300,L300P
<OPE-SBK (SR)><OPE-SRmini>
<WOP>
59 (2.32)
6.5
(0.26)
2 (0.08)
26.5 (1.04)
18 (0.71)
18
(0.71)
Mounting holes
80 (3.15)
79 (3.11)
1
2
STOP/
RESET
FUNC
STR
RUN
PRG
RUN
Hz
V
kW
A
%
ALARM
POWER
8 (0.31)
13
(0.51)
٘
Potentiometer is installed
only in OPE-SR
Ѯ
18 (0.71)
20.5 (0.81)
18 (0.71)
8.8 (0.35)
15.3
(0.60)
16.5
(0.65)
Mounting holes
Dimentions (Unit:mm (inch) Inches for reference only)
Operator
7 (0.28) 2.7 (0.11)
10
(0.39)
70 (2.76)
55 (2.17)
2-M3 depth5 (Reverse side)
2-M3 depth5 (Reverse side)
POWER RUN WARNING ALARM
REMOTE OPERATOR
80 (3.15)
103 (4.06)
123 (4.84)
8
(0.31)
13
(0.51)
6.5
(0.26)
103 (4.06)
2
(0.08)
26.5
(1.04)
18 (0.71)
18
(0.71)
Ѯ
Mounting holes
REMOTE
ESC SET
OPE
KEY ENABLED
1
2
43
READ
STOP
RESET
WRITE
<SRW-0J, SRW-0EX>
FWD RUN REV RUN
<OPE-SBK (SR)><OPE-SRmini> < SRW-0J, SRW-0EX, WOP>
*1) Production has been stopped.
ICS-1 (1m
ICS-3 (3m
Applied Cable
