Page 65Phantom PS1000
16 SPECIFICATIONS
Performance specifications are nominal, unless otherwise indicated, and are
subject to change without notice.
16.1 GENERAL
Channels............................................................. All USA, International and Canadian
Input Voltage ....................................................................................... 13.8 VDC ±20%
Current Drain
Standby ........................................................................................................... 0.3 A
Receive ........................................................................................................... 0.5 A
Transmit...................................................................................5.5 A (Hi); 1.5 A (Lo)
Dimensions ................................................................2-1/2” H x 6-5/16” W x 6-5/16” D
(64 H x 160 W x 160 D mm)
Flush-Mount Dimensions ................................................... 2” H x 5-5/16” W x 5-1/8” D
(50 H x 136 W x 130 D mm)
Weight...................................................................................................... 2.2 lbs (1 kg)
16.2 TRANSMITTER
Frequency Range ..................................................................156.025 to 157.425 MHz
RF Output ......................................................................................25 W (Hi); 1 W (Lo)
Conducted Spurious Emissions................................................. 80 dB (Hi); 60 dB (Lo)
Audio Response ..............................................................within +1/-3 of a 6 dB/octave
pre-emphasis characteristic at 300 to 3000 Hz
Audio Distortion ...................................................................................................... 5 %
Modulation ..................................................................... 16K0G3E, for DSC 16K0G2B
Frequency Stability (-20°C to +50°C)............................................................ ±0.0005%
FM Hum and Noise ..............................................................................................50 dB
16.3 RECEIVER
Frequency Range ..................................................................156.050 to 163.275 MHz
Sensitivity
20 dB Quieting ............................................................................................0.35 µV
12 dB SINAD ...............................................................................................0.25 µV
Squelch Sensitivity (Threshold)...................................................................0.13 µV
Modulation Acceptance Bandwidth ................................................................. ±7.5 kHz
Selectivity
Spurious and Image Rejection ................................................... better than -70 dB
Intermodulation and Rejection at 12 dB SINAD......................... better than -70 dB
Audio Output (CMP25)............................................................................................2 W
Audio Response ............................................................within + 2/–8 of a 6 dB/octave
de-emphasis characteristic at 300 to 3000 Hz
Frequency Stability (-20°C to +50°C)........................................................... ±0.0005 %
Channel Spacing................................................................................................ 25 kHz
DSC Format ............................................................................................. RTCMSC101
NMEA Input/Output ........................................................................ Output - DSC, DSE
Input - GLL, GGA, RMC and GNS
