The FUSION Marine Stereo makes it possible to have 3 ‘Zones’, that
have independent volume control.
Zone 1 and 2 are powered and can be linked, Zone 3 requires a
FUSION Marine Amplifier. All Zones have adjustable volume limits.
Note: If the Zone is selected as ‘Off’ The features are not available.
ZONE SETUP
Press the ‘Menu’ button and select ‘Zones’. Select the Zone you wish
to setup.
ZONE ON/OFF
Select ‘On’ if Zones are present on the vessel.
Note: Zone 1 cannot be turned OFF
VOLUME LIMIT
Select ‘Volume Limit’ to set the desired maximum output volume for
each individual Zone.
LINK ZONE 1 + 2
Allows the volume control to operate Zones 1 + 2 as a combined pair.
The Zone set up for Zone 1 and 2 can be configured separately when
in this mode.
Press the ‘Menu’ button and select ‘Zones’. Select ‘Zone 1’ then
‘Link Zone 1 + 2’. Select ‘On’ to activate this feature.
016
ZONE OPERATION
ZONE OPERATION
DESCRIPTION COLOUR
Battery +12VDC Yellow
Accessory +12V switched Red
Negative Ground Black
Remote Amplifier Turn On Blue/White
Note: The +12V switched and +12V battery can be joined for some
installation requirements.
ANTENNA CONNECTION
Connect an AM/FM marine antenna.
AUX INPUT
Connect an Auxiliary source to the left and right RCA
(White = L, Red = R).
iPod CONNECTION (MS-CD600 and MS-AV600 only)
Connect the 1.5m iPod accessories lead MS-IP15L (not included), or
connect the MS-IPDOCK (not included)
SIRIUS SATELLITE RADIO (For use in USA only)
Connect to SiriusConnect™ tuner (not included)
WIRED REMOTE (MS-WR600)
Connect a marine wired remote to the CANbus system connector.
Up to 3 remotes can be connected to the system.
VIDEO CONNECTION (MS-AV600)
Connect the composite video or the S-Video output to a TV / LCD
monitor.
CONNECTIONS
ZONE CONNECTIONS
Zone 1 White = Speaker Left Positive
White / Black = Speaker Left Negative
Grey = Speaker Right Positive
Grey/ Black = Speaker Right Negative
Zone 2 Green = Speaker Left Positive
Green / Black = Speaker Left Negative
Purple = Speaker Right Positive
Purple / Black = Speaker Right Negative
Note: Speaker connection (2 Ohm Stereo minimum). 2 pairs of 4 Ohm
speakers per channel can be connected in parallel to achieve 2 Ohm
configuration.
Zone 3/Lineout Low level output
(For connection to external amplifier)
White RCA= Left Output
Red RCA = Right Output
Orange RCA= Subwoofer Output
Note: Line Output / Sub can both be independently assigned to Zone 1,
Zone 2 or as a unique Zone 3.
005
CONNECTIONS
Refer to the wiring diagram for reference (pg 6)
LINEOUT
Lineout gives you the ability to connect a FUSION Marine Amplifier.
Note: The lineout can independently be assigned to Zone 1, 2 or 3.
Press the ‘Menu’ button and select ‘Zones’. Select ‘Lineout’. Select the
Zone you are assigning to the Lineout.
SUBWOOFER
Change the assigned zone of the subwoofer. Also adjust the sub
level and filter.
SUBOUT ZONE
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Subout Zone’. Select the desired subwoofer zone.
Note: The subwoofer can independently be assigned to Zone 1, 2 or 3.
SUB FILTER
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Sub Filter’. Select the desired frequency.
SUB LIMIT
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Sub Limit’. Select the desired maximum subwoofer output volume.
Note: Press and Hold the ‘Rotary Encoder’ for quick access to
subwoofer level adjustment
