Specications
Elite 5x, Mark 5x & Mark 5x Pro
General
Case size
5.4” H (134mm) x 6.8” W (174mm); 6” H
(152mm) with bracket
Display
Mark: (5” diagonal) High-contrast lm
Supertwist LCD; 16-level grayscale denition;
480x480 monochrome
Elite: (5” diagonal) Enhanced Solar MAX™
480x480 color
Backlight
Mark: White LED
Elite: Cold cathode uorewscent lamp (10
levels)
Power
Transmit
power
Mark 5x: 1600W PTP 200W RMS
Mark 5x Pro: 2400W PTP; 300 RMS
Elite 5x: 4000 PTP; 500W RMS
Power
requirement
12V
Voltage input 10 to 17V
Current drain Typical: .25A
Fuse type 3 amp automotive (not supplied)
Sonar
Max depth
Mark 5x: 800ft (244m)
Mark 5x Pro/Elite 5x: 1000ft (305m)
Transducer
frequency
Mark 5x: 200kHz
Mark 5x Pro/Elite 5x: 83/200kHz
Max speed 70mph
Transducer Skimmer with built in temp sensor
Transducer
cable
20 feet (6m)
