8 Attach the engine stop switch lanyard
to a secure place on your clothing, your
arm or leg while operating.
8 Do not attach the lanyard to clothing
that could tear loose. Do not route the
lanyard in such a way that it could
become entangled, preventing it from
functioning.
8 Avoid accidentally pulling the lanyard
during normal operation. Loss of
engine power means the loss of most
steering control. Also, without engine
power, the boat could slow rapidly.
This could cause people and objects in
the boat to be thrown forward.
NOTE:
The engine cannot be started with the
lock-plate removed.
1 Lock-plate
2 Lanyard
q
w
000647
000610
DN UP
EMU01323
Power Tilt Switch
The power tilt adjusts the motor angle in
relation to the transom. The power tilt
switch is located on the tiller handle.
Pushing the switch “UP” tilts the motor
up. Pressing the switch “DN” tilts the
motor down. When the switch button is
released, the motor will stop in its current
position.
NOTE:
Refer to the section “TILTING UP/DOWN”
for instructions on usage.
