Advanced Secure 8-Port and 16-Port DVI-I KVM
Color Code Chip Installation
The KVM Switch’s port-selector buttons can be color-coded for easier
identification. Refer to the installation instructions below.
Note: You may have to remove the existing black color chip first.
Port Name Label
The included network-name and blank labels can be placed in the
area underneath the port-selector buttons for port identification.
Insert color chip Remove color chip
with a standard paperclip
Console
12V, 1.5A
Audio
Display
PS2 K PS2 MMouse Keyboard
CAC
4
K/M CACAudio
Video
3
K/M CACAudio
Video
2
K/M
CAC
Audio
Video
1
K/M CACAudio
Video
