30
SERVSWITCH™ SUMMIT
Figure 4-9. The Channel Configuration Menu for a KV1502A (shown after
a hypothetical cascaded system configuration is finished).
e. Continue using the up- and down-arrow keys and [PageUp] and
[PageDown] keys to move the yellow highlight to the Name field for the
channel number where a subsidiary Base Unit is installed and press
[Enter]. The highlight should turn light blue.
f. Type in the name that you want to assign to the subsidiary Base Unit on
this channel (the highlight should turn green when you start typing). Press
[Enter] when you’re finished, then press “S” to save the new name. All
other paths (channels) by which that subsidiary Base Unit is attached to the
Base Unit above it will be given the same name automatically.
g. Press [F2] to reopen the Selection Menu; make sure that the channel(s) of
the second-tier Base Unit are properly established. All paths to that Base
Unit should be displayed in purple.
h. Press [F5] to go back to the Administration Menu. Select Channel
Configuration again. Select a channel that has been configured for the
subsidiary Base Unit you just set up. Press [G] to bring up a dedicated
Channel Configuration menu for the subsidiary Base Unit.
i. Edit the names of all computer CPUs attached to this subsidiary Base Unit.
Each highlight should turn green as you start typing. Press [Enter] when
you’re finished with each name. Press “S” to save all of the new names.
Channel Configuration
Summit 16x64 Page: 1/8
ChID Name Scn Device
---- ------------ -- -------
1 03 CPU
2 NT40-Mail 03 CPU
3 Wins95_Bob 03 CPU
4 Wins98_Jack 03 CPU
5 Matrls_8x32 -- S832
6 NT40-Fax 03 CPU
7 Mrktng_8x32 -- S832
8 PubSrv_8x32 -- S832
---- ------------ -- -------
ScrlLock | Scan | Skip NCSL
Edit G FKey S Esc
