Step 6
Connect a Category 5 or 6 cable to the
blinking 10/100 Ethernet port.
Connect the other end of the cable to the
Ethernet port on your PC.
Wait until the port LEDs on the switch and
your PC or laptop are either green or blinking
green. Green LEDs mean a successful
connection.
Troubleshooting
If the port LEDs are not green after about 30
seconds, make sure that:
• You connected the Ethernet cable to the
blinking 10/100 Ethernet port (not to an
uplink port such as the dual-purpose
port).
• You are using a Category 5 or 6 cable and
that the cable is not damaged.
• The other device is turned on.
You can ping IP address 169.254.0.1 to verify
the connection.
