154 Specifications
www.dell.com | support.dell.com
Audio
Audio type two-channel high definition audio (Azalia)
Audio controller IDT STAC9205 Codec
Stereo conversion 24-bit (analog-to-digital and digital-to-
analog)
Interfaces:
Internal high definition audio (Azalia) codec
External microphone-in connector, stereo
headphones/speakers connector
Speaker one 4-ohm speaker
Internal speaker amplifier 2-W channel into 4 ohms
Volume controls volume control buttons, program menus
Display
Type (active-matrix TFT) WXGA or WXGA+
Active area (X/Y) 303.74 x 189.84
Dimensions:
Height 206 mm (8.11 inches)
Width 320 mm (12.6 inches)
Diagonal 358.14 mm (14.1 inches)
Operating angle 0° (closed) to 180°
Viewing angles:
WXGA Horizontal 40/40°
WXGA Vertical 15/30°
WXGA+ Horizontal 40/40°
WXGA+ Vertical 15/30°
Pixel pitch:
WXGA 0.2373
WXGA+ 0.2109
Power Consumption (panel with
backlight) (typical):
WXGA 6.2 W (max) with no inverter losses
WXGA+ 7.5 W (max) with no inverter losses
