P61A!Pellet!Stove
#8!Installing!through!the!ceiling!vent
Through! the! ceiling! vent,! follow! PLvent
manufacturers!recommendations!when!using !wall!and
ceiling!pass!through.
Fig.!14
No! insulation! or
other!combustible
materials! are
allowed!within! 3"
of!the!PL!vent!pipe.
PL! vent! manufacturer's
firestop!spacer!and!support
(See! Page! 9! for
corner
installation
clearances)
Minimum! flue! vent
configuration
It!is!recommended!that
outside!air!be!installed!with!this
venting!configuration.
Min.!above!ground!level
18"
Storm!collar
Flashing
3"!min.
3"!min.
12"!min.
3"!min.
Venting
Fig.!15
Fig.!16
