LaserJet 4Si M
HP Parts Reference Guide™
Paper Path Parts
Kit
C2087-67902 Maintenance kit - Replacement parts after 200K pages (240V) includes, transfer roller & clip, 6 pickup separation rollers,
duplex roller, and (240V) fusing assembly
NO LONGER SUPPLIED
C2087A Maintenance kit - Replacement parts after 200K pages (240V) includes, transfer roller & clip, 6 pickup separation rollers,
duplex roller, and (240V) fusing assembly
NO LONGER SUPPLIED
Motor
234
RG5-0027-000CN Motor assembly - Drive for paper pickup roller
NO LONGER SUPPLIED
235
RG5-0040-060CN Main motor assembly
PC Board
238
RG5-0034-100CN Paper input board
Paper Input Unit
236
C2009-69007 Paper input unit - Complete paper feed
REQUIRES RETURN OF DEFECTIVE PART
RG5-0025-220CN New Part for C2009-69007
Paper Refeed
237
RG5-0056-000CN Paper refeed unit
Roller
239
RF5-0041-020CN Pickup separation roller - In paper input unit
NO LONGER SUPPLIED
240
RG5-0141-000CN Transfer charge roller (Black) - Held in place w/ blue clip
Roller Assembly
241
RG5-0161-090CN Registration assembly - Next set of rollers after paper pickup
NO LONGER SUPPLIED
Sensor
242
RG5-0116-000CN Output door sensor assembly
NO LONGER SUPPLIED
243
WG8-5038-020CN Photo sensor
NO LONGER SUPPLIED
Solenoid
244
RG5-0063-000CN Flapper solenoid (SL6) - Controls rear or top paper output
NO LONGER SUPPLIED
245
RG5-0064-000CN Duplex deflector (Feed guide) solenoid (SL7) - In job offset
246
RG5-0065-060CN Job offset solenoid
247
RH7-5031-000CN Clutch solenoid (24VDC) - Engages registration roller clutch
NO LONGER SUPPLIED
Spring
248
RS5-2021-000CN Compression spring for arm that holds right side of transfer roller
Power Supplies and Parts
Cable
249
RG5-0104-000CN Cable assembly which connects the DC controller to the high voltage power supply
NO LONGER SUPPLIED
Power Cord
8120-1351 Power cord (Mint Gray) - 17 AWG, 2.3m (7.5ft) long - Has straight (F) receptacle (For 240V in the UK, Hong Kong,
Singapore, Malaysia, and Brunei)
8120-1369 Power cord (Mint Gray) - 17 AWG, 2.0m (6.6ft) long - Has straight (F) receptacle (For 240V in Australia, New Zealand,
and China)
