7 Screw listing
This section provides specification and reference information for the screws and screw locks used in
the device. All screws listed in this section are available in the Screw Kit, spare part number 504614-001,
or in the Display Screw Kit, part number 509700-001.
Phillips PM1.6×2.5 screw
Color Quantity Length Thread Head diameter
Silver 2 2.5 mm 1.6 mm 4.0 mm
Where used: Two screws that secure the heat sink to the system board
Phillips PM1.6×2.5 screw 69
