Product Description
1. 3 D e s i g n O v e r v i e w
This section presents a design overview of key parts and features
of the HP Docking Station and HP Advanced Docking Station.
Refer to Chapter 3, “Illustrated Parts Catalog,” to identify
replacement parts, and Chapter 5, “Removal and Replacement
Procedures,” for disassembly steps.
The docking stations provide the following device connections:
■ Monitor stand port, for use with the HP Monitor Stand
■ Digital video (DVI) jack
■ Audio-out (headphone) jack
■ Audio-in (microphone) jack
■ RJ-11 (modem) jack
■ RJ-45 (network) jack
■ USB 2.0 connectors (3 on docking station, 5 on
advanced docking station)
■ Powered USB 2.0 port
■ S-Video out
■ Serial port
■ Parallel port
