Removal and replacement procedures 31
Rack bezel
To remove the component:
1. Power down the server (on page 27).
2. Extend the server from the rack (on page 28).
3. Remove the access panel.
4. Remove the bezel.
To replace the component, reverse the removal procedure.
Rack rails
NOTE: This procedure applies to rack servers only.
To remove the component:
1. Power down the server (on page 27).
2. Remove the server from the rack (on page 28).
3. Use a flat-head screwdriver to lift the spring tab.
