Removal and Replacement Procedures
Maintenance and Service Guide 5–65
9. Slide the system board shield to the left 1 until it clears the
USB board frame.
10. Remove the system board shield 2.
Removing the System Board Shield, HP Pavilion dv4000 Models
System Board Shield Spare Part Number Information
System board shield (for use with HP Pavilion dv4000 models) 403915-001
