Shading Architecture
Shading ArchitectureShading Architecture
Shading Architecture
16 textures per pixel in fragment programs
Window ID clipping functionality
Hardware accelerated line stippling
Fully programmable GPU (OpenGL2.0/DirectX 9.0c class)
Long fragment programs (up to 65,536 instructions)
Long vertex programs (up to 65,536 instructions)
Looping and subroutines (up to 256 loops per
vertex program)
Dynamic flow control
Conditional execution
High Level Shader
High Level ShaderHigh Level Shader
High Level Shader
Languages
LanguagesLanguages
Languages
Optimized compiler for Cg and Microsoft HLSL
OpenGL 2.0 and DirectX 9.0c support
Open source compiler
High-Resolution
High-ResolutionHigh-Resolution
High-Resolution
Antialiasing
AntialiasingAntialiasing
Antialiasing
12-bit subpixel sampling precision enhances AA quality
Rotated-grid full-scene antialiasing (RG FSAA)
16x FSAA dramatically reduces visual aliasing artifacts or "jaggies" at
resolution up to 1920 x 1200
Display Resolution
Display ResolutionDisplay Resolution
Display Resolution
Support
SupportSupport
Support
Dual Dual Link DVI- I output-drives digital displays at resolutions up to 3840
x 2400 @ 41 Hz
Internal 400 MHz DACs - Two analog displays up to 2048 x 1536 @ 75 Hz
each
nView Architecture
nView ArchitecturenView Architecture
nView Architecture
Advanced multi-display desktop & application management seamlessly
integrated into Microsoft Windows.
Supported Graphics APIs
Supported Graphics APIsSupported Graphics APIs
Supported Graphics APIs
OpenGL 2.0 ICD with immediate mode support for all OGL primitive types
DirectX 9.0c
Available Graphics
Available GraphicsAvailable Graphics
Available Graphics
drivers
driversdrivers
drivers
Microsoft Windows XP, Linux - Full Open GL implementation, complete with
NVIDIA and ARB extensions.
HP qualified drivers may be preloaded or available from the HP support web
site:
http://welcome.hp.com/country/us/eng/software_drivers.html
ATI FireGL V3100
ATI FireGL V3100ATI FireGL V3100
ATI FireGL V3100
Graphics Card
Graphics CardGraphics Card
Graphics Card
(PCI
Express)
Form factor
Form factorForm factor
Form factor
ATX
Graphics controller
Graphics controllerGraphics controller
Graphics controller
RV370
Bus type
Bus typeBus type
Bus type
PCI-Express x16
Memory
MemoryMemory
Memory
128 MB 200MHz DDR unified frame buffer, Z-buffer and Texture storage
Connectors
ConnectorsConnectors
Connectors
1 DVI-I analog/digital and 1 VGA analog monitor output
Multi-monitor support
Multi-monitor supportMulti-monitor support
Multi-monitor support
Dual integrated display controllers supporting up to 2048x1536 @ 85Hz on
both displays
RAMDAC
RAMDACRAMDAC
RAMDAC
Dual 400 MHz integrated
QuickSpecs
HP xw4300 Workstation
HP xw4300 WorkstationHP xw4300 Workstation
HP xw4300 Workstation
Technical Specifications - Graphics
DA - 12260 Worldwide — Version 14 — March 1, 2006
Page 64
