EN47
Controls
1 Diopter Adjustment Control ................. ੬ pg. 14
2 Lens Cover Open/Close Ring................ ੬ pg. 16
3 5-Second Recording Button
[5SEC. REC] ......................................... ੬ pg. 20
4 Power Zoom Lever [T/W]..................... ੬ pg. 18
5 Picture Stabilizer Button
[P.STABILIZER] ..................................... ੬ pg. 20
6 Program AE Button [P.AE]..................... ੬ pg. 22
7 Fade/Wipe Button [EFFECT] ................. ੬ pg. 21
8 •Rewind Button [
2
, REW] ................ ੬ pg. 36
•Retake Rewind Button [RETAKE R]..... ੬ pg. 19
•Quick Review Button [ R] ............. ੬ pg. 19
9 •Fast-Forward Button [
3
, FF] ............ ੬ pg. 36
•Retake Forward Button [RETAKE F] .... ੬ pg. 19
0 Stop Button [5 , STOP]......................... ੬ pg. 36
! Play/Pause Button
[
4
/6, PLAY/PAUSE]............................. ੬ pg. 36
@ Select Dial [+, –, PUSH] ................ ੬ pg. 11, 26
# MENU/DISPLAY Button ................. ੬ pg. 17, 26
$ •Counter Reset/Memory Button
[COUNTER R/M] .............................. ੬ pg. 38
•Recording Mode Button [SP/EP]......... ੬ pg. 12
% EJECT Switch ....................................... ੬ pg. 13
^ Recording Start/Stop Button.................. ੬ pg. 16
& Power Switch ................................ ੬ pg. 16, 36
* Battery Release Switch
[BATTERY RELEASE] .............................. ੬ pg. 8
( PUSH Button ....................................... ੬ pg. 13
Connectors
) DC IN Jack ............................................ ੬ pg. 9
The connectors q to e are located beneath the
cover.
q Video Output Connector ...................... ੬ pg. 40
w Audio Output Connector ..................... ੬ pg. 40
e J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
r Tally Lamp ........................................... ੬ pg. 16
t Power Lamp ........................................ ੬ pg. 16
Other Parts
y Battery Pack Mount ............................... ੬ pg. 8
u Viewfinder ........................................... ੬ pg. 14
i Grip Strap ............................................ ੬ pg. 14
o Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
p Microphone
For use when recording.
Q Eyepiece.............................................. ੬ pg. 42
W Shoulder Strap Eyelets .......................... ੬ pg. 15
E Clock Battery Slot ................................ ੬ pg. 10
R Tripod Mounting Socket ....................... ੬ pg. 15
