EN87
Controls
1 E-MAIL CLIP REC Button
(GR-DVM75 only)................................੬ pg. 61
2 D. SOUND PLAY Button
(GR-DVM75 only)................................੬ pg. 56
3 •MENU Wheel [+, –, PUSH] ...............੬ pg. 38
•LCD Monitor Brightness
Control [+, –] ....................................੬ pg. 18
4 •Power Zoom Lever [T/W] ..................੬ pg. 19
•Speaker Volume Control
[VOL.] ...............................................੬ pg. 21
5 Power Switch
[ , , , OFF] ............................੬ pg. 16
6 Lock Button .........................................੬ pg. 16
7 Recording Start/Stop Button .................੬ pg. 18
8 Snapshot Button
[SNAPSHOT] ...............੬ pg. 26, 27, 50, 59, 60
9 •FOCUS Button ..................................੬ pg. 51
•BLANK Button ...................................੬ pg. 24
0 Battery Release Switch
[BATT. RELEASE] ....................................੬ pg. 8
! OPEN/EJECT Switch .............................੬ pg. 12
@ SELECT Button (GR-DVM75 only) ... ੬ pg. 30, 32
# JUMP Button (GR-DVM75 only) ..........੬ pg. 30
$ INDEX Button
(GR-DVM75 only)..........................੬ pg. 30, 56
% •Play/Pause Button [4/6] ..................੬ pg. 21
•NIGHT-ALIVE Button.........................੬ pg. 45
^ •Fast-Forward Button [3] ...............੬ pg. 21
•PROGRAM AE Button .......................੬ pg. 46
& •Stop Button [5] .................................੬ pg. 21
•BACKLIGHT Button...........................੬ pg. 52
* •Rewind Button [2] .......................੬ pg. 21
•EXPOSURE Button.............................੬ pg. 52
( VIDEO/DSC Switch [VIDEO, ]
(GR-DVM75 only)................................੬ pg. 16
) CARD OPEN Switch
(GR-DVM75 only)................................੬ pg. 14
q Diopter Adjustment Control .................੬ pg. 10
Connectors
The connectors w to r are located beneath a cover.
w Digital Video Connector
[DV IN/OUT] (i.link*) ..............੬ pg. 58, 74, 75
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
e •Audio/Video Input (GR-DVM75 only)/
Output Connector
[AV IN/OUT or AV OUT] ......੬ pg. 22, 57, 70
•Headphone Connector [ ]
(GR-DVM75 only) .............................੬ pg. 66
r DC Input Connector [DC IN] .............੬ pg. 8, 9
Indicators
t Tally Lamp .....................................੬ pg. 18, 40
y Power Lamp...................................੬ pg. 16, 18
u CHARGE Lamp ......................................੬ pg. 8
Other Parts
i LCD Monitor..................................੬ pg. 18, 19
o Battery Pack/Jack Box Mount ...........੬ pg. 8, 23
p Speaker................................................੬ pg. 21
Q Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
W Stereo Microphone ..............................੬ pg. 66
E Flash (GR-DVM75 only).......................੬ pg. 54
R Flash Sensor (GR-DVM75 only)
Be careful not to cover this area, as it contains a
sensor required by the flash.
T Lens
Y Lens Protector
When using an optional lens filter (commercially
available), you must first detach the lens
protector.
U Remote Sensor .....................................੬ pg. 62
I Grip Strap ............................................੬ pg. 10
O Viewfinder ...........................................੬ pg. 10
P Viewfinder Cleaning Hatch ..................੬ pg. 84
a Memory Card Cover
(GR-DVM75 only)................................੬ pg. 14
s Cassette Holder Cover .........................੬ pg. 12
d Tripod Mounting Socket .......................੬ pg. 10
