EN45
Controls
1 Video Light Switch [LIGHT OFF/AUTO/ON]
(GR-AX761 only) ................................. ੬ pg. 18
2 Stop Button [STOP] .............................. ੬ pg. 30
3 •Retake Rewind Button [RETAKE R]..... ੬ pg. 17
•Quick Review Button [ R] ............ ੬ pg. 17
•Rewind Button [R] ............................. ੬ pg. 30
4 Play/Pause Button ................................ ੬ pg. 30
5 •Retake Forward Button [RETAKE F] .... ੬ pg. 17
•Fast-Forward Button [F] ..................... ੬ pg. 30
6 •Fade/Wipe Button [FADE/WIPE] ........ ੬ pg. 19
•Counter Reset/Memory Button
[COUNTER R/M] .............................. ੬ pg. 31
7 Program AE Button [P. AE].................... ੬ pg. 20
8 Digital Effect Button [DIGIFECT] .......... ੬ pg. 21
9 REFRESH Button .................................... ੬ pg. 6
0 EJECT Switch ....................................... ੬ pg. 13
! Close Button ........................................ ੬ pg. 13
@ •MENU Wheel [–, +] .......................... ੬ pg. 22
•BRIGHT Wheel [–, +]
(GR-AXM231 only) ..................... ੬ pg. 14, 30
•TRACKING Wheel [–, +] ................... ੬ pg. 31
# 5-Second Recording Button
[5 SEC. REC] ....................................... ੬ pg. 17
$ •Power Zoom Lever [T/W] .................. ੬ pg. 16
•Speaker Volume Control [VOL.]
(GR-AXM231 only) ........................... ੬ pg. 30
% •Picture Stabilizer Button
[P. STABILIZER] ................................. ੬ pg. 16
•Time Base Corrector Button [TBC] ..... ੬ pg. 31
^ Power Switch
[ , OFF, , ] ...................... ੬ pg. 14, 30
& Recording Start/Stop Button.................. ੬ pg. 14
* Battery Release Switch
[BATTERY RELEASE] .............................. ੬ pg. 6
( Diopter Adjustment Control ................... ੬ pg. 8
Connectors
The connectors ) to w are located beneath the
cover.
) Audio Output Connector [A] ................ ੬ pg. 32
q Video Output Connector [V] ................ ੬ pg. 32
w DC IN Connector............................... ੬ pg. 6, 7
Indicators
e CHARGE Lamp...................................... ੬ pg. 6
r •Power Lamp ..................................... ੬ pg. 14
•REFRESH Lamp ................................... ੬ pg. 6
Other Parts
t LCD Monitor (GR-AXM231 only) ... ੬ pg. 14, 15
y Shoulder Strap Eyelets ............................ ੬ pg. 9
u Eyepiece
i Battery Pack Mount ............................... ੬ pg. 6
o Viewfinder ............................................. ੬ pg. 8
p Speaker (GR-AXM231 only) ................. ੬ pg. 30
Q •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor (GR-AX761 only) ....... ੬ pg. 36
W Grip Strap.............................................. ੬ pg. 8
E Microphone......................................... ੬ pg. 39
R Video Light (GR-AX761 only) ............... ੬ pg. 17
T Tripod Mounting Socket ......................... ੬ pg. 9
