EN43
Controls
1 Diopter Adjustment Control ................. ੬ pg. 15
2 Lens Cover Open/Close Ring................ ੬ pg. 16
3 5-Second Recording Button
[5 SEC. REC] ........................................ ੬ pg. 20
4 Power Zoom Lever [T/W]..................... ੬ pg. 18
5 •Picture Stabilizer Button
[P.STABILIZER] .................................. ੬ pg. 18
•Time Base Corrector Button ............... ੬ pg. 32
6 Program AE Button [P.AE]..................... ੬ pg. 22
7 Fade/Wipe Button [EFFECT] ................. ੬ pg. 21
8 •Retake Rewind Button [RETAKE R]..... ੬ pg. 19
•Quick Review Button [ R] ............. ੬ pg. 19
•Rewind Button [REW] ....................... ੬ pg. 31
9 •Retake Forward Button [RETAKE F] .... ੬ pg. 19
•Fast-Forward Button [FF] ................... ੬ pg. 31
0 Stop Button [STOP] .............................. ੬ pg. 31
! Play/Pause Button [PLAY/PAUSE] ......... ੬ pg. 31
@ Select Wheel [PUSH]........................... ੬ pg. 23
# MENU/DISPLAY Button ................. ੬ pg. 17, 23
$ •Recording Mode Button [SP/EP] ......... ੬ pg. 12
•Counter Reset/Memory Button
[COUNTER R/M] .............................. ੬ pg. 32
% EJECT Switch ....................................... ੬ pg. 10
^ Recording Start/Stop Button.................. ੬ pg. 16
& Power Switch
[ , OFF, AUTO, PRO.].............. ੬ pg. 16, 31
* Battery Release Switch
[BATTERY RELEASE] .............................. ੬ pg. 9
( PUSH Button ....................................... ੬ pg. 10
Connectors
) DC IN Connector................................... ੬ pg. 9
The connectors q to r are located beneath the
cover.
q Video Output Connector ...................... ੬ pg. 34
w Audio Output Connector ..................... ੬ pg. 34
e S-Video Output Connector ................... ੬ pg. 34
r J Terminal
[JLIP (Joint Level Interface Protocol) Connector]
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
t Power Lamp ........................................ ੬ pg. 16
Other Parts
y Battery Pack Mount ............................... ੬ pg. 9
u Viewfinder ........................................... ੬ pg. 15
i Grip Strap ............................................ ੬ pg. 15
o •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. ੬ pg. 36
p Microphone......................................... ੬ pg. 39
Q Eyepiece.............................................. ੬ pg. 50
W Shoulder Strap Eyelets .......................... ੬ pg. 15
E Clock Battery Slot ................................ ੬ pg. 10
R Tripod Mounting Socket ....................... ੬ pg. 15
