15
ENGLISH
GETTING
STARTED
Remote Control
Infrared Beam Transmitting Window
ZOOM (T/W) Buttons
(Zoom in/out during playback.)
Up Button
Skip Backward Button
Left Button
Back Button
PLAYLIST Button
START/STOP Button
S.SHOT (Snapshot) Button
INFO Button
Skip Forward Button
PLAY/PAUSE/SET Button
Right Button
Next Button
Down Button
INDEX Button*
DISP Button
NOTE
You can move the zooming area with the up/
down/left/right button during zoom in playback
mode.
* Each time you press INDEX, the screen
switches as shown below:
mode:
Index Screen ↔ Group Index Screen
mode:
Index Screen ↔ Date Index Screen
Camcorder
Touch sensor
LCD Monitor
SD Cover
SD Card Slot B (੬ p. 21)
SD Card Slot A (੬ p. 21)
Audio/Video Connector [AV] (੬ p. 30, 36)
HDMI Mini Connector [HDMI] (੬ p. 30)
Component Connector [COMPONENT]
(੬ p. 30)
Direct Disc Button [DIRECT DISC]
(੬ p. 35)/Information Button [INFO]
(੬ p. 25)
Mode Switch [ , ]
Export Button [EXPORT] (੬ p. 42)
Playback/Recording Mode Switching
Button [PLAY/REC]
Upload Button [UPLOAD] (੬ p. 43)
Power Switch [
]
(You can turn off the camcorder by
pressing and holding this button.)
Menu Button [MENU] (੬ p. 44)
OK Button [OK]
LED Light (੬ p. 24)
Lens Cover/Lens
Stereo Microphone
Remote Sensor
Camera Sensor
Video Recording Start/Stop Button
[START/STOP] (੬ p. 22)
Access Lamp [ACCESS] (Blinks when you
access fi les. Do not turn off the power or
remove the battery pack/AC adapter while
accessing fi les.)
Power/Charge Lamp [POWER/CHARGE]
(Blinks when you charge the battery.)
Still Image Shooting Button [SNAPSHOT]
(੬ p. 22, 23)
Zoom Lever [W , T] (੬ p. 24)
Speaker Volume Control [–VOL+] (੬ p. 28)
Speaker
DC Connector [DC] (੬ p. 18)
USB Connector [
] (੬ p. 34, 38)
Grip Strap
Fasten
Belt Strap
Stud Hole
Tripod Mounting Socket (੬ p. 20)
Battery Release Button [BATT.] (੬ p. 18)
