68
HD-ILA Device Projection Type
Video Format
Power Source
Power Consumption
Model
SD (NTSC, 480i, 480p), HD (1080i, 720p)
AC 120V, 60 Hz
180W
110W High-Pressure Mercury Lamp
Screen Size
52 inch / 132 cm
measured diagonally,
16:9 ratio
Speakers 10 cm round X 2
Audio Output Full Range - 10W + 10W
External Input Jacks
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBvfs) high impedance
Component Input
Jacks
Y: 1Vp-p positive, 75 ohms (negative sync provided)
Pb/Pr: 0.7 Vp-p 75 ohms
S-Video Input Jacks
Y: 1Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Digital–In
HDMI jack x 1
Note: The Digital–In terminal is not compatible with picture signals of a
personal computer
48 1/2 x 35 7/8 x 16 3/8
122.9 x 91.1 x 41.5
Remote control unit x 1 / AA batteries X 2
Dimensions (inch)
W X H X D (cm)
Weight (lbs / kg)
Accessories
Audio Output Jacks
(FIX)
FIX : 500mVrms (-4dBvfs) Low impedance (1000 Hz when modulated 100%)
84 / 38
Projection Source
HD-52G587 HD-61G587
61 inch / 154.9 cm
measured diagonally,
16:9 ratio
57 3/8 x 41 1/8 x 18 5/8
145.6 x 104.2 x 47
95 / 43
PC Input Jack
Analog RGB D-SUB (15 pin) x 1
• PC signal is available. Refer to page 22 for details on the signals which
can be input.
Specifications
Specifications subject to change without notice.
