EN 19
Names of
special-effects
playback
Reverse Forward
Search Play
Slow-Motion
*Still
Slow-Motion
Play Search
(Time Jog**) (Time Jog**)
-9x -7x -5x -3x -1x -1/2x 0 1/2x 1x 1.5x 2x 3x 5x 7x 9x
-7x -3x -1/2x 0 1/2x 1x 1.5x 2x 5x 9x
Audio is output.
Audio is not Audio is Audio is
Audio is output.
output. output. output.
TimeScan
Speed LP
Speed SP
Audio output
● The recorder's TIME JOG & SCAN indicator lights during TimeScan.
● The speed is shown during TimeScan in the upper right corner of the TV screen for approx. 5 seconds. (The display may be
distorted.)
● To resume normal playback, press PLAY.
● When using the recorder's TIME SCAN SHUTTLE ring, the playback speed may not change in the correct step if it is turned
too fast.
● Picture and audio may become distorted when the recording speed changes. When this happens, resume normal playback
once, and then try using TimeScan again.
● The picture may be noisy or there may be a loss of colour when you change the playback speed. (More noise will appear with
LP recordings.)
● Noise may appear or the upper part of the picture may be distorted during still, frame-by-frame playback, 2x search of LP
recordings, or depending on the tape being used.
● Picture may appear distorted in comparison to normal playback.
● When normal playback resumes from search (including TimeScan), still, slow motion or frame-by-frame playback, the picture
may jitter vertically momentarily depending on the type of TV being used.
● In TimeScan mode there will be a time lag between the video and the audio and noise may appear in the audio signal.
● TimeScan sound quality will differ in comparison to normal playback.
● When material such as music videos where there is non-stop sound (very few breaks in the soundtrack) are viewed at 1.5x or
2x normal speed, the audio playback may be faster than normal.
● Depending on the type of tape contents, the sound may not be clear during forward slow-motion playback.
● Time Jog cannot be activated by pressing PAUSE for longer than 2 seconds.
● When the playback direction is reversed, it takes approximately 6 seconds until sound is heard.
● Picture will be monochrome with an LP-recorded MESECAM tape during TimeScan.
● When playing back an NTSC tape, the speeds differ from those listed above and are not shown on the TV screen, and the
TIME JOG & SCAN indicator does not light.
Also, depending on the type of tape being used, the picture may be distorted and there may be a loss of colour even when in
the TimeScan mode.
● TimeScan at -1/2x, 1/2x and 1.5x normal speed are not possible with a MESECAM tape.
If you don't want to hear TimeScan audio, set "TIME SCAN AUDIO" to "OFF" (See below).
TimeScan Audio
The audio output can be set ON/OFF during TimeScan. Select ON/OFF as required.
* The default setting is "ON".
1 Press MENU to access the Main Menu screen.
2 Move the highlight bar (pointer) to "MODE SET" by pressing %fi, then press OK or .
3 Move the highlight bar (pointer) to "TIME SCAN AUDIO" by pressing %fi, then press OK or to select "ON" or "OFF".
4 Press MENU to return to the normal screen.
%
%
**Still mode cannot be engaged using the remote control's or button. Still mode can be engaged by
pressing the PAUSE button. In the Still mode, the TIME JOG & SCAN indicator does not light even though
you can hear TimeScan audio.
**Smooth slow motion delivering an uninterrupted moving image without distortion.
MODE SET
AUTO TIMER OFF
O. S. D. ON
B. E. S. T. ON
AUTO SP=LP TIMER OFF
DIGITAL 3R ON
POWER SAVE OFF
S-VHS AUTO
NEXT PAGE
[5∞] =
[MENU] : EXIT
PREVIOUS PAGE
EDIT OFF
AV2 SELECT VIDEO
COLOUR SYSTEM PAL/NTSC
TIME SCAN AUDIO ON
[5∞] =
[MENU] : EXIT
HR-S8500E HR-S8500EH
MODE SET
AUTO TIMER OFF
O. S. D. ON
B. E. S. T. ON
AUTO SP=LP TIMER OFF
DIGITAL 3R ON
S-VHS AUTO
EDIT OFF
NEXT PAGE
[5∞] =
[MENU] : EXIT
PREVIOUS PAGE
AV2 SELECT VIDEO
COLOUR SYSTEM PAL/NTSC
TIME SCAN AUDIO ON
[5∞] =
[MENU] : EXIT
%
