14 EN
120MIN
3MIN
2MIN
MIN 119MIN
1MIN0MIN
NOTE:
You should already have performed the procedures listed
below. If not, do so before continuing.
●
Power (
੬
pg. 6)
●
Load A Cassette (
੬
pg. 13)
●
Recording Mode Setting (
੬
pg. 12)
●
Tape Length Setting (
੬
pg. 12)
●
Grip Adjustment (
੬
pg. 8)
●
Viewfinder Adjustment (
੬
pg. 8)
1
Press in the tabs on the lens cap to remove it. Set the
Power Switch to “ ” or “ ”. The power lamp
lights and the camcorder enters the Record-Standby
mode. “PAUSE” is displayed in the viewfinder.
2
Press the Recording Start/Stop Button. “ ” appears
in the viewfinder while recording is in progress.
To Stop Recording . . .
.... press the Recording Start/Stop Button. The camcorder
re-enters the Record-Standby mode.
Power Switch
Recording Start/Stop Button
Tape remaining
time indicator
(Approximate)
(Now calculating)
(Blinking) (Blinking) (Blinking)
RECORDING
Basic Recording
Power Switch Position
: Suitable for standard recording using NO special effects or manual adjustments.
: Allows you to set recording functions using the menus for more creative capabilities.
OFF : Switches off the camcorder.
: Allows you to play back your recordings.
During shooting
