EN 35
Speed
Names of
special-effects
playback
Reverse Forward
Search Play Slow-Motion *Still Slow-Motion Play Search
-7x -5x -3x -1x -1/6x -1/18x 0 1/18x 1/6x 1x 2x 3x 5x 7x
Audio is output.
Audio is Audio is Audio is not
Audio is output.
not output. output. output.
TimeScan
Audio output
* Still mode cannot be engaged using the TIME SCAN buttons. Still mode can only be engaged by pressing
the PAUSE button.
● The speed is shown in the upper right corner of the TV screen for approx. 5 seconds.
● The TimeScan search speed is the same for SP and EP recordings.
● To resume normal playback, press PLAY.
● Picture may be distorted at the position where the recording speed is switched.
● The picture may be noisy for a moment when you change the playback speed.
● During high-speed search with a tape containing both SP and EP recordings, the search speed will change automatically to 7x
normal playback speed with TimeScan when the recording tape speed switches from EP to SP.
● Depending on the tape in use, noise may appear or the upper part of the picture may be distorted.
● Picture may appear distorted in comparison to normal playback.
● In TimeScan mode there will be a time lag between the video and the audio and noise may appear in the audio signal.
● TimeScan sound quality will differ in comparison to normal playback.
● When material such as music videos where there is non-stop sound (very few breaks in the soundtrack) are viewed at 2x
normal speed, the audio playback may be faster than normal.
● When the playback direction is reversed, it takes approximately 6 seconds until sound is heard.
If you don't want to hear TimeScan audio, set "TIMESCAN AUDIO" to "OFF".
TimeScan Audio
The audio output can be set ON/OFF during TimeScan. Select ON/OFF as required. *The default setting is "ON".
1 Press MENU to access the Main Menu screen.
2 Move the highlight bar (arrow) to "FUNCTION SET" by press-
ing CH5∞ or TIME SCAN%fi, then press OK or TIME SCAN
.
3 Move the highlight bar (arrow) to "TIMESCAN AUDIO" by
pressing CH5∞ or TIME SCAN %fi, then press OK or TIME
SCAN to select to "ON" or "OFF".
4 Press MENU to return to the normal screen.
%
FUNCTION
=AUTO TIMER OFF
SUPERIMPOSE ON
AUTO SP
=EP TIMER OFF
VIDEO STABILIZER OFF
2ND AUDIO RECORD OFF
AUDIO MONITOR HI-FI
NEXT PAGE
SELECT WITH (5,∞) AND (OK)
PRESS (MENU) TO END
PREVIOUS PAGE
AV COMPU-LINK ON
VIDEO CALIBRATION ON
=TIMESCAN AUDIO ON
SELECT WITH (5,∞) AND (OK)
PRESS (MENU) TO END
%
