B
Load cassettes
Insert the playback cassette into the playback VCR and the
cassette to be recorded on into the recording VCR.
C Select input mode on recording VCR
Select the correct external input on the recording VCR.
On this VCR (when using this VCR as the recording VCR);
Select “L-1” — when connecting the other VCR to the audio/video
(or S-video) input connectors on the rear panel.
Select “F-1” — when connecting the other VCR to the audio/video
(or S-video) input connectors on the front panel.
Press AUX or CH+/– on the Remote. Or push the JOG dial, then
turn it to the left or right.
D Select video input connector on recording VCR
When using this VCR as the recording VCR, select the appropriate
mode depending on the connector being used (
੬ pg. 19).
When using S-VIDEO input connector on the front panel, set
“FRONT AUX INPUT” to “S-VIDEO”.
When using S-VIDEO IN connector on the rear panel, set “REAR
AUX INPUT” to “S-VIDEO”.
When using VIDEO input connector on the front panel, set
“FRONT AUX INPUT” to “VIDEO”.
When using VIDEO IN connector on the rear panel, set “REAR
AUX INPUT” to “VIDEO”.
E
Select edit mode
Set the edit mode to “ON” for the VCRs if such a mode is
equipped.
● On this VCR, set “PICTURE CONTROL” to “EDIT” (
੬ pg. 18).
F Start playback
Press PLAY (4) on the playback VCR.
G
Start recording
Press REC (7) on the recording VCR.
Audio Dubbing
Audio Dubbing replaces the normal audio sound of a previously
recorded tape with a new soundtrack.
A Make connections
Connect an audio cable between the VCR’s audio input
connectors and the audio component’s audio output connectors.
● When connecting a monaural audio component, use only the
VCR’s AUDIO L input connector.
● Audio Dubbing is possible by using the audio input connectors
on the front panel or on the rear panel.
B Select input mode
Select “F-1” —when connecting the audio component to the
audio input connectors on the front panel.
Select “L-1” —when connecting the audio component to the
audio input connectors on the rear panel.
Press AUX or CH+/– on the Remote. Or push the JOG dial, then
turn it to the left or right.
C
Locate start point, and engage Audio Dubbing mode
Load a cassette and press PLAY (4) on the VCR. Press PAUSE (9)
at the point where you want to start dubbing, then press A.DUB.
● The VCR enters the Audio Dubbing Pause mode. “⅜” blinks
and “$” lights on the display panel.
D
Start dubbing
Engage the Play mode of the audio component, then press PLAY
(4) on the VCR. Audio Dubbing begins at this point.
● To pause dubbing, press PAUSE (9). Press PLAY (4) to resume
dubbing.
E End Audio Dubbing
Press STOP (8) on the Remote or STOP/EJECT (0) on the VCR,
then engage the Stop mode of the audio component.
NOTES:
● When monitoring the sound during Audio Dubbing, the normal
soundtrack is automatically selected. If you wish to hear the
Hi-Fi or mixed sound (Hi-Fi + normal soundtracks), press
A.MONITOR to select “NORM HI-FI”. (
੬ pg. 11, “Selecting
monitor sound”)
● Audio Dubbing stops automatically when the counter reaches
“0:00:00”, and the VCR enters the Play mode. Check the
counter reading on the screen before dubbing.
● “DAY/TIME INSERT” (
੬ pg. 19) is not available during Audio
Dubbing.
● Audio Dubbing is not possible with a cassette whose record
safety tab has been removed. If you want to record onto a tape
with its record safety tab removed, set “REC SAFETY” to “OFF”
(
੬ pg. 19).
● When playing back an audio-dubbed tape, press A.MONITOR
to select the soundtrack you wish to hear. (੬ pg. 11, “Selecting
monitor sound”)
● Picture may be distorted if you pause Audio Dubbing.
Various connection for editing tapes
The following three methods can be used for editing tapes.
● VHS to S-VHS editing (VIDEO-VIDEO connection):
Although the picture quality is inherently limited by the
original VHS quality, the edited tape has better picture quality
than those made by VHS-to-VHS editing.
● S-VHS to VHS editing (VIDEO-VIDEO connection):
Since the original source is recorded in S-VHS mode, the
edited tape has better picture quality than those made by
VHS-to-VHS editing.
● S-VHS to S-VHS (S-VIDEO connection):
Original picture quality of S-VHS made can be duplicated
with minimal picture degradation. This is the best editing
method you can use on S-VHS VCRs.
Normal track
Video and
Hi-Fi track
Before audio
dubbing
After audio
dubbing
To AUDIO input
This VCR
CD player, etc.
To AUDIO output
CONTINUED ON NEXT PAGE
