70 EN
USING THE REMOTE CONTROL UNIT
(cont.)
ROSYNCH
O.1
–
ADJUSTMENT OF VCR/CAMCORDER
TIMING
4
Point the remote control at the camcorder’s remote
sensor and press R.A.EDIT ON/OFF to make the
Random Assemble Editing menu disappear, then
press the MENU wheel. The Menu Screen appears.
5
Rotate the MENU wheel to select “ VIDEO” and
press it. The VIDEO Menu appears. Then, rotate it to
“SYNCHRO” and press it. The value for “SYNCHRO”
is highlighted.
6
Based on the diagnostics performed (੬ pg. 69), you
can now advance the VCR’s record timing by rotating
the MENU wheel towards “+”. You can also delay the
VCR’s record timing by rotating the MENU wheel
towards “–”. The adjustment range is from –1.3 to
+1.3 seconds, in 0.1-second increments.
Press the MENU wheel to finish the setting.
7
Rotate the MENU wheel to select “
1
RETURN” and
press it twice.
Now perform Random Assemble Editing beginning
with step 4 on page 67.
NOTES:
●
Before performing actual Random Assemble Editing, do
a few Random Assemble Editing trial runs to check
whether the value you have input is appropriate or not,
and make adjustments accordingly.
●
Depending on the recorder, there may be situations
where the timing difference cannot be fully corrected.
Display
MENU Wheel
VCR
(Recording deck)
TV
