5. OPERATION (Cont’d)
Ⅵ RESET
It returns the values set on the MENU screen to the initial
values.
There are three different RESET items: Individual file reset,
All files reset, and Reset for the TOTAL SETTING only.
Note:
Do not perform any other operations during the resetting.
Otherwise, the values will not be initialized properly.
ⅷ Individual file reset
The current selected file setting values are reset to the initial
values.
1.
Press the RESET button with something which has a pointed
tip.
2.
When the reset starts, the LED for the selected file blinks
for approx. 3 sec.
Note:
The TOTAL SETTING screen will not be initialized.
ⅷ All files reset
The setting values for all of the 16 files are initialized.
1.
Press the RESET button with something which has a pointed
tip while pressing the SET button simultaneously.
2.
When resetting starts the LEDs for the FILES 1 - 4 are turned
off for 5 sec. Then the LED of the file selected before the
reset blinks for approx. 3 sec. The reset is completed when
the LED stops blinking, and lights.
Note:
The TOTAL SETTING screen will not be initialized.
FILE SETTING (Cont’d)
Item
Initial Values of Scene File A
Initial Values
LENS TYPE
IRIS CONTOROL
SHUTTER
AUTO
AUTO
NORMAL
- - - - - - - - - -
0 dB
- - - - - - - - - -
+18 dB
NORMAL
NORMAL
3200K
AUTO
OFF
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
NORMAL
ALTERNATE
OFF
FRAME
- - - - - - - - - -
- - - - - - - - - -
NORMAL
NORMAL
OFF
OFF
100%
110%
ON
NORMAL
NORMAL
ADJUST
NORMAL
LEVEL
GAIN
LEVEL
ALC MAX
IRIS DETECT
DETECT AREA
COLOR TEMP
WHITE BAL
SHADING MODE
LEVEL <R>
LEVEL <G>
LEVEL <B>
FREEZE
FREEZE TRG
HI-RESO
CAPTURE
RANDOM SHUT
SLOW SHOT
DETAIL
MASTER BLACK
NEGA
AUTO KNEE
KNEE POINT
WHITE CLIP
GAMMA
FLARE <R>
FLARE <B>
ABL
ABL LEVEL
ⅷ Reset for the TOTAL SETTING only
The values of the TOTAL SETTING which are common for all
files are initialized.
1.
Press the RESET button with something which has a pointed
tip while pressing the ITEM button simultaneously.
2.
When the reset starts, the LED for the currently selected
FILE blinks for approx. 3 sec. The reset is completed when
the LED stops blinking, and lights.
Item
TOTAL SETTING Initial Values
Initial Values
LENS CONTROL
INDICATOR
CABLE LENGTH
H PHASE
SC COARSE
SC FINE
D-SUB OUT R/G/B
OFF
CONTROLLER
OFF
5M
0
0
0
ON SYNC
