EN 73
Controls
1 Power Zoom Button ........................... ੬ pg. 16
Page Button........................................
੬ pg. 51
2 Select Dial ......................................... ੬ pg. 22
3 Multi-Function Control
•EFFECT Button .................................
੬ pg. 24
•WIDE Button ...................................
੬ pg. 25
•TITLE Button ....................................
੬ pg. 26
•SUPER LOLUX Button .....................
੬ pg. 25
4 PUSH Button...................................... ੬ pg. 13
5 DATE/TIME Button ............................. ੬ pg. 18
COUNTER R/M Button.......................
੬ pg. 40
6 P. [Picture] STABILIZER Button ........... ੬ pg. 17
7 REW Button ....................................... ੬ pg. 38
RETAKE R [Quick Review] Button ......
੬ pg. 17
8 PLAY/PAUSE Button ........................... ੬ pg. 38
9 FF Button ........................................... ੬ pg. 38
RETAKE F Button ................................
੬ pg. 17
0 STOP Button ...................................... ੬ pg. 38
! EJECT Switch...................................... ੬ pg. 13
@ Function Navigator Dial
[MENU Jog Dial] ................................ ੬ pg. 9
# LIGHT OFF/AUTO/ON Switch ........... ੬ pg. 19
$ BATT. [Battery] RELEASE Switch ......... ੬ pg. 6
% Dioptre Adjustment............................ ੬ pg. 10
^ System Select
[VIDEO/D.S.C.] Switch .... ੬ pg. 14, 38, 44, 51
& MODE Button .............................. ੬ pg. 20, 44
* SNAPSHOT Button ...................... ੬ pg. 20, 44
( LENS COVER Switch.......................... ੬ pg. 14
) Recording Start/Stop Button................ ੬ pg. 14
q Power Switch ................... ੬ pg. 14, 38, 44, 51
Connectors
w DC IN Jack ......................................... ੬ pg. 7
The jacks e to i are located beneath the jack
cover.
e External Microphone Input Jack ......... ੬ pg. 68
r J terminal
[ JLIP (Joint Level Interface Protocol) Connector]
•Connect the editing cable when performing
Random Assemble Editing (
੬ pg. 62 – 65).
•It is used to connect the camcorder to a device
such as a personal computer.
For further detail consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with
a J terminal.
t Digital Jack ........................................ ੬ pg. 59
y AUDIO OUT Connector .................... ੬ pg. 42
u VIDEO OUT Connector ..................... ੬ pg. 42
i RF DC OUT Connector ...................... ੬ pg. 42
Indicators
o Tally Lamp ......................................... ੬ pg. 14
p Power Indicator.................................. ੬ pg. 14
Other Parts
Q Video Light......................................... ੬ pg. 19
W Microphone ....................................... ੬ pg. 68
E •Camera sensor
Be careful not to cover this area; built-in
here is the sensor necessary for shooting.
•Remote Sensor................................. ੬ pg. 61
R Clock Battery Compartment ............... ੬ pg. 8
T Battery Pack Mount ............................ ੬ pg. 6
Y LCD window
A
Picture Mode Display
B
Remaining Number of Shots Indicator
U Electronic Viewfinder ......................... ੬ pg. 10
I Shoulder Strap Eyelets ........................ ੬ pg. 11
O Grip Strap .......................................... ੬ pg. 10
P Tripod Mounting Socket ..................... ੬ pg. 11
