Instructions KWPST – SW Upgrade
80-B6013-10 Rev. B Kyocera Wireless Corp. Proprietary 3
10. Browse and select the appropriate
*.ROM file to place into the phone.
(SX1112.ROM)
11. Press Start.
12. Once complete, remove the phone
from the cradle.
13. Perform a hard reset. Hold the
backlight button for five seconds and
press the reset button with the stylus.
14. Release stylus and continue to hold
the backlight button until you see the
PalmOS splash screen, and then text
will appear that reads “Erase all
data?”
15. Press page-up to complete the
operation.
16. Programming is complete.
This upgrades the phone module of the Kyocera Smartphone. All phone related data is saved
by default by the KWPST.
1. Activate QCP-6035’s Service
Interface Mode by the following
steps:
2. Press and hold the LCD Backlight
button, and tap the Data/Fax icon
on the screen, then release the LCD
backlight button. Service Interface
mode is now activated and KWPST
will recognize the phone in the
following steps.
