Install memory, firmware, or option cards
Installing a memory card Follow the instructions in this section to
install a printer memory card. Memory
cards must have 168-pin connectors.
Note: Some memory options offered for other Lexmark
printers cannot be used with your printer. Refer to the
publications CD for memory specifications.
1 Remove the system board access
cover (see Page 22).
Warning: Memory cards are easily damaged by static
electricity. Touch something metal on the printer before
you touch a card.
2 Unpack the memory card.
Avoid touching the connection
points along the edge of the card.
Save the packaging.
3 Push open the latches on both
ends of the memory connector.
4 Align the notches on the bottom of
the card with the notches on the
connector.
5 Push the memory card firmly into
the connector until the latches on
either end of the connector snap
into place.
It may require some force to fully
seat the card.
6 Make sure each latch fits over the
notch on the end of the card.
Latch
Notch
Connection points
What do I do now?
Task Go to page…
Installing a firmware card 25
Installing a hard disk 26
Installing an option card 28
Replacing the system board access cover 30
