MIG: Wire Feeder/Welders
www.lincolnelectric.com/mig-welders
Power MIG
®
215
Simple Control for Sheet Metal Welding
• More Output—rated at 215 amps/22 volts @ 30% duty cycle,
with an amperage range of 30-250 amps DC – the highest
rating and widest amperage range in its class.
• Diamond Core Technology
™
delivers a forgiving arc, excellent
out-of-position arc action, a wide voltage sweet spot at a given
wire feed speed and low spatter.
• Rugged cast aluminum industrial wire drive features dual
driven rolls, regulated wire feed speed control, easy-turn
numeric tension indicator, brass-to-brass connections and
Lincoln’s 100% wire supporting split wire guide system.
• Generous 15 ft. (4.5 m) gun and cable assembly makes
it easy to reach your work.
• Seven tapped voltage ranges make it easy to
select the right procedure for your application.
• 115 volt auxiliary power receptacle for grinders,
tool chargers.
• Three-year warranty on parts and labor. (90 days on gun.)
Power MIG
®
255C
The Professional’s Choice!
SM
for Job Shop Fabrication
• Diamond Core Technology
™
delivers a wide voltage sweet spot across
the welding range, low spatter levels and a forgiving arc on steel,
stainless and aluminum—even for demanding out-of-position work.
• Rugged cast aluminum industrial wire drive features dual driven rolls,
easy-turn numeric tension indicator, brass-to-brass gun connections
and Lincoln’s
®
100% wire-supporting split wire guide system.
• Digital meters display, preset wire feed speed and voltage,
and actual amperage and voltage while welding.
• Spool Gun Ready—electronics and second gas solenoid
are built-in to drive either the Magnum
®
SG or Magnum
®
250LX
™
spool gun.
• 115V auxiliary receptacle (208/230V model only) powers
a grinder or other equipment.
• Base Unit Includes: Power MIG
®
255C; Magnum
®
250L Gun & 15 ft (4.5 m) “quick-connect“ cable assembly
eqipped with fixed gas nozzle assembly; Work Clamp & Cable, 10 ft. (3.0 m); 10 ft. (3.0 m) 230V Input Power
Cable w/Plug (208/230V model only); .035"/.045" (0.9/1.2 mm) Drive Rolls & Guide for Steel; Gas Regulator &
Hose Kit for CO
2
or Argon blend gases.
• Three-year warranty on parts and labor. (90 days on gun.)
Product Product Input Power Rated Output Input Current @ H x W x D Net Weight
Name Number Voltage/Phase/Hertz Current/Voltage/Duty Cycle Rated Output Output Range inches (mm) lbs.(kg)
Power MIG
®
255C K2417-1 208/230/1/60 250A/26V/40% 50/46A 30-300 Amps — —
One-Pak
®
w/Spool Gun 50-700 ipm WFS
Power MIG
®
255C K2416-1 208/230/1/60 50/46A (1.3 -17.7 m/min) 31.8 x 18.9 x 38.8 240 (109)
K2416-2 230/460/575/1/60 47/24/19A Max. OCV: 40V (808 x 480 x 985) (with gun)
DC
1
PHASE
60
50
Hz
CV
DC
1
PHASE
60
Hz
CV
The Power MIG
®
215 offers the autobody and sheet metal
fabrication industries top welding performance and a host
of professional features not often found at this price.
The Power MIG
®
255C sets the standard for MIG and
flux-cored welding in industrial production, job shop
fabrication, maintenance or repair work.
Processes
• MIG
• Flux-Cored
Output Input
Unit Includes
• Magnum
®
250L Gun, 15 ft. (4.5 m)
• Work Cable and Clamp
• Contact Tips
• Cable Liner
• Drive Rolls
• Adjustable Gas Regulator & Hose
Key Options
• K2378-1 Medium Canvas Cover
• K1809-1 Magnum
®
SG Spool
Gun/Adapter
•
More options at end of section
Literature
E7.51
Processes
• MIG
• Flux-Cored
Output Input
One-Pak
®
Spool Gun Pkg. Includes
• Power MIG 255C
• Magnum
®
SG Spool Gun
• Magnum
®
SG Cable Adapter Plug
• Spool Gun Holder
• Dual Cylinder Mounting Kit
Key Options
• K1702-1 Dual Cylinder Kit
• K2378-1 Medium Canvas Cover
• K2490-1 Magnum
®
250LX
™
Spool
Gun
•
More options at end of section
Literature
E7.54
Product Product Input Power Rated Output Input Current @ H x W x D Net Weight
Name Number Voltage/Phase/Hertz Current/Voltage/Duty Cycle Rated Output Output Range inches (mm) lbs.(kg)
Power MIG
®
215 K2326-1 208/230/1/50/60 215A/22V
(1)
/30% 45/41A 30-250 Amps DC 31.8 x 18.9 x 38.8 198
190A/23V/40% 42/38A 50-700 ipm WFS (808 x 408 x 985) (90)
170A/24V/60% 39/35A (1.3 -17.7 m/min)
Max. OCV: 39V
(1)
21V on 220V 50 Hz input.
