*3 The following table shows the error code area assignment for the Access target CPUs 1 to 64
(Buffer memory address: 4008 to 4071).
*4 The following table shows the assignment of the Trigger buffer overflow count areas for Jobs 1 to
64 (Buffer memory address: 11520 to 11583).
Table 3.17 Access target CPU 1 to 64, error code areas
Name
Access target CPU 1 to 64, error code areas
1 2 3 4 5 6 7 8 9 10
Access target CPU 1 to 10, error codes 4008 4009 4010 4011 4012 4013 4014 4015 4016 4017
11 12 13 14 15 16 17 18 19 20
Access target CPU 11 to 20, error codes 4018 4019 4020 4021 4022 4023 4024 4025 4026 4027
21 22 23 24 25 26 27 28 29 30
Access target CPU 21 to 30, error codes 4028 4029 4030 4031 4032 4033 4034 4035 4036 4037
31 32 33 34 35 36 37 38 39 40
Access target CPU 31 to 40, error codes 4038 4039 4040 4041 4042 4043 4044 4045 4046 4047
41 42 43 44 45 46 47 48 49 50
Access target CPU 41 to 50, error codes 4048 4049 4050 4051 4052 4053 4054 4055 4056 4057
51 52 53 54 55 56 57 58 59 60
Access target CPU 51 to 60, error codes 4058 4059 4060 4061 4062 4063 4064 4065 4066 4067
61 62 63 64
Access target CPU 61 to 64, error codes 4068 4069 4070 4071
Table 3.18 Trigger buffer overflow count areas for Jobs 1 to 64
Name
Trigger buffer overflow count areas for Jobs 1 to 64
1 2 3 4 5 6 7 8 9 10
Trigger buffer overflow counts for Jobs 1 to 10 11520 11521 11522 11523 11524 11525 11526 11527 11528 11529
11 12 13 14 15 16 17 18 19 20
Trigger buffer overflow counts for Jobs 11 to 20 11530 11531 11532 11533 11534 11535 11536 11537 11538 11539
21 22 23 24 25 26 27 28 29 30
Trigger buffer overflow counts for Jobs 21 to 30 11540 11541 11542 11543 11544 11545 11546 11547 11548 11549
31 32 33 34 35 36 37 38 39 40
Trigger buffer overflow counts for Jobs 31 to 40 11550 11551 11552 11553 11554 11555 11556 11557 11558 11559
41 42 43 44 45 46 47 48 49 50
Trigger buffer overflow counts for Jobs 41 to 50 11560 11561 11562 11563 11564 11565 11566 11567 11568 11569
51 52 53 54 55 56 57 58 59 60
Trigger buffer overflow counts for Jobs 51 to 60 11570 11571 11572 11573 11574 11575 11576 11577 11578 11579
61 62 63 64
Trigger buffer overflow counts for Jobs 61 to 64 11580 11581 11582 11583
