BThe picture will then
be enlarged to 1.5
times the normal size.
The remote control unit functions during D.ZOOM (digital zoom)
Press the F,G,IandHbuttons to move the enlarged area which you want to project.
Press the D.ZOOM +/- buttons to change the enlargement ratio.
Press the MENU button to return to the normal screen.
Press the
II
or
HH
button to switch between the still picture screen
and moving picture screen.
Press the ENTER button to capture the present moving picture in a
still window.
Press the MENU button to return to the previous screen.
[
Enlarging the picture (D.ZOOM)
Adjusting the volume (VOLUME)
Press the D.ZOOM +/- button.
Press the VOLUME +/- button.
BPress the + button to raise the volume.
BPress the - button to lower the volume.
NOTE:
B
The enlargement ratio can be changed within the range of x1 to x2, in steps of
0.1. When RGB signals are being input, the enlargement ratio can be changed
within the range of x1 to x3, except when the “FRAME LOCK” is set to “ON”.
BIf the type of signal being input changes while the digital zoom function
is being used, the digital zoom function will be cancelled.
NOTE:
BYou can also select “VOLUME” from the
“MAIN MENU” to adjust the volume.
Displaying two screens (INDEX WINDOW)
This function lets you store a picture which is being projected into memory,
so that you can display a still picture and a moving picture on the screen.
BThe aspect ratio of
the screen changes
and the image is
vertically elongated
in comparison to a
normal image.
Press the INDEX WINDOW button.
NOTE:
BWhen the screen size is changed, the picture’s aspect ratio will also
change. Make sure that you fully understand the notes on “ASPECT” on
page 40 before using the “INDEX WINDOW” function.
B“INDEX WINDOW” on the “MAIN MENU” is the same function.
