Exploded View and Parts List
7-4
This Document can not be used without Samsung's authorization
13
16
15
14
Separate FRONT.
-
Separate FRONT from FRONT Ass`y following
indicated direction.
Separate Key Pad.
-
Separate Key Pad from FRONT Ass`y.
Separate SPK Bracket.
-
Lift SPK Bracket from FRONT Ass`y.
UNSCREW FRONT
2
Points.
Bracket Disassembly
:
refer to
5/6
page
UNSCREW
2
POINTS
