PART NO. DESCRIPTIONREF NO QTY.
Controls Group
Footnotes
1 1919438 4 NUT, Hex Lock ESNA, 5/16-18, Black
2 1713784 1 CLAMP
3 1722524A 1 FOOT PEDAL & BRAKE ARM ASSEMBLY
4 1715834 1 PEDAL, Foot, Forward
5 1721577 1 PAD, Brake Pedal
6 1715835 1 PEDAL, Foot, Reverse
7 1960221 5 CLIP, Hair Pin, Black
8 1921319 1 WASHER, 1/4, Black
9 1931333 4 CARRIAGE BOLT, 5/16-18 x 3/4, Black
10 1713855 1 KNOB, 1/4-20 Thread
11 1714385 1 ROD, Parking Brake, Yellow
12 1930591 1 CAPSCREW, Hex Head, Whiz Lock 5/16-18 x 3/4, Black
13 1723794A 1 BRACKET
14 1931277 1 NUT, Hex, 5/16, Black
15 2165068 1 SPRING, Extension, 6-1/2" Long
16 1722529 1 LEVER & ROD ASSEMBLY
17 1722974 1 CABLE, Forward/Reverse
18 1960261 1 PIN, Yoke, Drilled, 1/4 x 3/4, Black
19 1711115 2 PIN, Clevis, 11/32 x 1-1/4
20 1919326 1 WASHER, 5/16, Black
21 1722616 1 CABLE, Brake Control
22 1722617 1 CABLE, Clutch Control
23 1935048 1 NUT, Hex Flange Lock, 5/16-18, Black
24 1717728 1 GUIDE BELT & STUD ASSEMBLY
25 1708360 1 SPRING, Compression
26 1960608 1 NUT, Hex Center Lock, 1/4-20
27 1722975 2 CLEVIS
The above parts group applies to the following Mfg. Nos.:
2005
19
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694772 - Lancer
1694785 - 4416XL
1694786 - Lancer
1694787 - 4416XL
TP 400-4206-01-LN-SM
