STR-DG520
3-284-083-11(1)
Inputs
Analog Sensitivity: 500 mV/
50 kohms
S/N
3)
: 96 dB
(A, 500 mV
4)
)
Digital (Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
Digital (Optical) S/N: 100 dB
(A, 20 kHz LPF)
Outputs (Analog)
AUDIO OUT Voltage: 500 mV/10
kohms
SUB WOOFER Voltage: 2 V/1 kohm
Tone
Gain levels ±6 dB, 1 dB step
3)
INPUT SHORT (with sound field and tone
bypassed).
4)
Weighted network, input level.
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
Antenna Loop antenna
Intermediate frequency
450 kHz
5)
You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. While holding down TUNING
MODE, press ?/1. All preset stations will be
erased when you change the tuning scale. To reset
the scale to 10 kHz (or 9 kHz), repeat the
procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p/75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p/75 ohms
P
B/CB: 0.7 Vp-p/75 ohms
P
R/CR: 0.7 Vp-p/75 ohms
80 MHz HD Pass Through
General
Power requirements
Power output (DIGITAL MEDIA PORT)
DC OUT: 5 V, 0.7 A MAX
Power consumption
Power consumption (during standby mode)
0.3 W
Dimensions (w/h/d) (Approx.)
430 × 157.5 × 318 mm
(16 7/8 × 6 2/8 × 12 5/8
inches) including
projecting parts and
controls
Mass (Approx.) 7.7 kg (16 lb 16 oz)
Supplied accessories
Operating Instruction (this manual)
Quick Setup Guide (1)
FM wire antenna (aerial) (1)
AM loop antenna (aerial) (1)
Remote commander (RM-AAU020) (1)
R6 (size-AA) batteries (2)
Design and specifications are subject to
change without notice.
Area code Tuning scale
10 kHz step 9 kHz step
U, CA 530 –
1,710 kHz
5)
531 –
1,710 kHz
5)
Area code Power requirements
U, CA 120 V AC, 60 Hz
Area code Power consumption
U220 W
CA 300 VA
For details on the area code of the
component you are using, see page 3.
