Activation of the outputs from a zone.
The freezing of inputs from a zone.
Unfreezing of inputs from one zone.
Initiation of a recording.
The “Day” and “Night” programs activated in accordance with a schedule for
each day of the week, together with the possibility of establishing a calendar
with holidays when the system employs the “Night” program.
Stores up to 10 ten-second video image sequences. The sequence capture is
triggered by the activation of an input. The length of the sequences is
programmed independently for each camera and you can chose values between
one and ten seconds. You may also chose the pre-alarm percentage (earlier
images prior to the input activation) that you wish between the values of 0% and
100%.
Configuration and programming through the embedded WEB application. One
http server integrated in the device offers html pages containing forms for quick
configuration.
LAN connection through an Ethernet port 10/100 baseT and RJ45 connector.
WAN connection
1
through:
V.24/V.35 port from 300bps up to 2 Mbps.
ISDN port at speeds of 64/128 Kbps.
X.21 port up to 2 Mbps.
Optional bi-directional audio channel over IP with transmission in G.723 or G.
729ª formats.
Remote awakening permitting automatic connection of the device to an Internet
supplier (in PSTN through an external modem with ring pattern and the ISDN
by call indication through the D channel).
Dynamic assignation of the IP address in the link protocols, point-to-point (PPP)
established over each of the basic access B channels or over Public Switch
Telephone Network – PSTN using an external modem.
Access control that limits access to the device configuration screens to users that
have an administrator password.
1
Availability depending on version.
