Reference [Rhythm]
ZOOM MRS-802
84
section can be used for numeric input, as described below.
The basic rules for creating a rhythm pattern sequence are as
follows.
• Select the pattern
Use status keys 1 - 9 and the [DRUM] key to enter a pattern
number with up to 3 digits. The display shows the pattern
number.
•Line up patterns
Use the “+” symbol to line up patterns. For example,
entering
0 + 1 + 2 will result in the following play
sequence.
• Repeat patterns
Use the “x” symbol to specify pattern repetitions. As in
regular arithmetic, multiplication symbols take precedence
over addition symbols. For example, entering 0 + 1 x 2 + 2
will result in the following play sequence.
•Link patterns
Use the “(“ and “)” symbols to link a group of patterns for
repetition. Strings enclosed by brackets are processed
together as a unit. For example, entering 0 + 1 + 2 x 2+ (3 +
4) x 2 will result in the following play sequence.
An example for creating the rhythm pattern sequence
0
→
1
→
2
→
3
→
2
→
3
→
4
is shown below.
HINT
If the formula does not fit on two lines, the indication scrolls
in steps of one character. If you use the cursor left/right keys
0 1 2
0 1 1 2
10 2 2
3 4 3 4
0
0+
0+1+
0+1
0+1+(2
0+1+(2+3
0+1+(2+3
)
0+1+(2+3
)x
0+1+(2+3
)x2
0+1+(2+3
)x2+
0+1+(2+3
)x2+4
0+1+(
0+1+(2+
Press
times
Press
times
Press
times
