SPECIFICATIONS
Power source 9 V alkaline battery (1)
Measuring modes Distance, continuous, area, volume, side
Measurable range *
1
1.64 ft to 164 ft (0.5 m to 50 m)
Display unit Feet, inches and meters
Laser
Laser: Visible light semiconductor laser 650 nm
Output: 1 mW or less (Class II *
2
)
Measuring accuracy (repeated) *
3
±0.06˝ (±1.5 mm)
Measuring time *
4
0.5 to 3 sec.
Minimum measurement unit 0.039˝ (1 mm)
Splash proof & dust-proof Protection Class IP54 *
5
(excluding battery compartment)
Battery life Approx. 30,000 measurements *
6
Operating temperature range 0°C to 40°C
Storage temperature range –20°C to 60°C
Auto power off *
7
Laser beam Approx. 30 sec.
Display Approx. 3 min.
Dimensions (H × W × D) 4-3/8˝ × 2-9/32˝ × 1-17/64˝ (111 mm × 58 mm × 32 mm)
Weight 0.3 lbs (140 g) (including battery)
*1 The measurable range may vary depending on the characteristics of the laser beam refl ected from the target surface and the surrounding
brightness.
*2 Laser class based on 21CFR part 1040.10.11
*3 The measuring accuracy may vary depending on the characteristics of the laser beam refl ected from the target surface and the surrounding
brightness.
*4 The measuring time may vary depending on the characteristics of the laser beam refl ected from the target surface and the surrounding
brightness.
*5 Water splashes and dust have no harmful eff ect.
*6 Battery life may be reduced depending on usage environment and type of battery.
*7 Time until the power turns off automatically when left unoperated.
