4-1
Specications
For detailed specications and warranty information of the PoleVault System components, refer to the device
manuals, or the product pages at www.extron.com.
Mounting hardware
PCM 340
Mounting ........................................ Drop ceiling mountable
Maximum load .............................. 50 lbs (22.7 kg)
Material ........................................... Baseplate and pipe: aluminum, tie wire: steel, 14 AWG, 70,000 psi tensile strength
Dimensions
Base plate ............................ 1.2" H x 26.4" W x 8.0" D, (2.9 cm H x 67.0 cm W x 20.3 cm D)
Pipe ...................................... 25" length, 1.5"-11.5 NPT
Adjustment ranges ........................ 1.5" - 23.0” drop, 21.5" adjustability in 0.5" steps
Product weight .............................. 4.5 lbs (2 kg)
Regulatory compliance
Safety ................................... CE, c-UL, UL
Vibration ......................................... ISTA 1A in carton (International Safe Transit Association)
PMK 550
Mounting
Pole mount ......................... Mountable to round projector mount poles, either standard 1.5” (3.8 cm) NPT pipes or pipes
with an outer diameter of 1.85” to 1.95” (4.7 cm to 5.0 cm) using included hardware
Maximum load .............................. 15 lbs (6.8 kg)
Material
Base plate ............................ Aluminum
Plate covers ........................ High impact plastic
Dimensions .................................... 3.0" H x 15.4" W x 11.9" D (7.6 cm H x 39.1 cm W x 30.2 cm D
Product weight .............................. 2.4 lbs (1.2 kg)
Regulatory compliance
Safety ................................... CE, c-UL, UL as an accessory for use with a UL Listed mount and projector
Vibration ......................................... ISTA 1A in carton (International Safe Transit Association)
UPB 25
Material ........................................... Steel
Maximum load .............................. 25 lbs (11.3 kg)
General dimensions ...................... Refer to UPB 25 manual
Product weight .............................. 3.7 lbs (1.7 kg)
Regulatory compliance
Safety .................................... CE, UL, c-UL as an accessory, for use with UL Listed mount and projector
Vibration ......................................... ISTA 1A in carton (International Safe Transit Association)
Devices
PVS 305SA
External power supply ................. 100 VAC to 240 VAC, 50-60 Hz, external; to 12 VDC, 5 A, regulated
Power input requirements ........... 12 VDC, 5 A
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling ........................................... Convection, vents on sides
Enclosure type .............................. Metal
Enclosure dimensions .................. 1.7" H x 8.7" W x 3.0" D (1U high, half rack wide) (4.3 cm H x 22.1 cm W x 7.6 cm D)
Product weight .............................. 2.5 lbs (1.1 kg), plus power supply 0.8 lbs (0.4 kg)
