SIS Command/Response Table
Command ASCII (Telnet)
(host - switcher)
Response
(switcher to host)
Video Configuration
Set the video signal type
X!
*
X2#
\ Typ
X!
=
X2#
]
View the video signal type
X!
\ Typ
X!
=
X2#
]
Status Commands
View all input status
LS Frq=
X2$
*
X2$
*
X2$
*
X2$
]
View paging sensor status
42S Sts42*
X#]
Mic Talk-over Threshold
Adjust talk-over threshold
2*
X2%
# Thr
X2%]
Decrement threshold
-* 2# Thr
X2%]
Increment threshold
+* 2# Thr
X2%]
View mic threshold
2# Thr
X2%]
Program Audio Ducking Level
Adjust audio ducking level
58 *
X2^
#
Adl
X2^
]
Increment audio ducking
+* 58#
Adl
X2^
]
Decrement audio ducking
-* 58#
Adl
X2^
]
View audio ducking
58#
Adl
X2^
]
Set Lineout Mode
Set lineout to variable
55*1# LineOut*
X2&]
Set lineout to fixed
55*2# LineOut*
X2&]
View lineout mode
55# LineOut*
X2&]
Set Audio Output Mode
Set audio output mode to mono
18*1#
PreAmpMod*
X@
]
Set audio output mode to stereo
18*2#
PreAmpMod*
X@
]
Set Output Volume Level
Specify volume
X^
V
VolX^]
Increment volume
+V
VolX^]
Decrement volume
-V
VolX^]
View volume
V
VolX^]
Paging Sensor Delay
Set paging sensor delay
75 *
X2(
# PageDly*
X2(]
View paging sensor delay
75# PageDly*
X2(]
] = CR/LF (carriage return/line feed) (hex 0D 0A)
} = CR (no line feed)
• = Space
E
= Escape key
X!
= Input numbers 1 through 4, and 7;
0 = all outputs muted (both audio and video)
1 and 2 = RGB inputs
3 and 4 = Composite video inputs
X@
= Audio mode
1 = Dual mono (default)
2 = Stereo
X#
= Status
0 = Off
1 = On
X^
= Volume, 0 - 100, default = 50
X2#
= Video type (inputs 3 and 4 only)
1 = Composite video (default)
2 = RGB
X2$
= Video signal status
1 = A video signal present
2 = No video signal detected
X2%
= 0 to 15 microphone talk-over threshold level range,
default = 6
X2^
= 0 to 30, program audio ducking level in talk-over mode,
default = 15
X2&
= Lineout status
1 = variable (default)
2 = fixed
X2(
= Paging delay on 1 second steps; default = 0 (disabled),
1 = 1.0 second, 2.0 = 2 second, ..., 8 = 8.0 second
PVS 305SA specic symbol denitions
N For a complete list of SIS commands for the PVS 305SA, refer to the PVS 305SA User’s Manual available online at www.extron.com
SIS
™
Commands
For full PoleVault device specifications, optional accessories, and part numbers, visit www.extron.com
