Front of Switch
All LEDs used by the Switch 800T are on the front panel. During the power-
on or reset cycles, all LEDs are on.
Switch Status LEDs
Figure D-1. Example of Status LEDs for the Switch 800T
Fault LED
Power LED
Self-test LED Security LED
RPS LED
