OPERATION
BND/LOU/ENT button (5) to start
playing the track.
Searching Directory or File Name
Press AS/PS button (6) for two times. It
enters into “Searching Directory or
File Name” in Digital Audio CD.
The unit searches files and directories
that have the same character which is
inputted by VOL +/- buttons (23&20).
Explain as follows:
- Use the VOL+/- buttons to select the
characters A to Z, blank, 0 to 9, _, -, +.
- Press SEL button (21) to confirm
entry of each characters.
- Press BND/LOU/ENT button (5) to
start the title search.
In case the selected title is a directory
name, display will show (‘ ‘), then
- Use the tune/seek/track buttons
/ (22&19) to list all songs
under this directory and select the
title.
- Press BND/LOU/ENT button (5) to
confirm and start the play.
- Repeat the above steps if the newly
selected title is again a directory.
Searching From Root Directory
Press AS/PS button (6) for three times.
The unit searches file or directory from
root by the tune/seek/track buttons
/ (22&19).
Select the desired directory/songs by
using the tune/seek/track buttons
/ (22&19) and BND/LOU/ENT
button (5) to confirm. If the selected title
is a song, it starts to play.
Searching From Current Directory
Press AS/PS button (6) for four times.
The unit searches file or directory from
current directory by the tune/seek/track
buttons
/ (22&19). The user can
select the directory or file in the
directory by the tune/seek/track buttons
/ (22&19). The selected file can be
played by pressing BND/LOU/ENT
button.
3) DISPLAY INFORMATION
Press DISP button (7) to show the
following information, such as the clock,
ID3 TAG (if available: song title, directory
name, artist name, other contents…)
(FOR WITH MP3 ID3 FUNCTION
VERSION ONLY) and other information.
USB PLAY OPERATION
On the back of the unit, there is a USB
cable, and you can connect a USB driver
through the USB interface.
When you connect a USB driver through
the interface, the unit will search the
MP3/WMA files and start to play it
automatically. In other modes, you can also
press MOD button (9) to select USB mode.
When playing the MP3/WMA files in the
device, the operation is the same with the
MP3 operation described above.
Note：
z The main unit can only support the
standard USB-memory device.
z USB MP3 player is not a standard
which means different brand name or
different models have their own
standard. So our product cannot
support all MP3 players.
z When connecting an MP3 player and
there has normal battery in the player
(non rechargeable battery), you should
remove the battery from the MP3 player
then connect it to the USB interface.
Otherwise, it may cause battery burst.
z When in USB play mode, be sure not
to remove the USB driver from the USB
interface.
CAUTION
When there are important files in the USB
device, do not connect it to the main unit to
play. And don’t play the CD-R/RW disc that
has important files in it. Because any wrong
