BLT370
Pairing Sequence
Note:
• Please refer to Clarion
Bluetooth
®
Audio Transmitter and Cradle for iPod owner’s
manual for the
Bluetooth
®
Audio Transmitter operation below.
Between
Bluetooth
®
Audio/Mobile-phone Transceiver and
Bluetooth
®
Audio Transmitter
1. Make sure the Transmitter is connected to an audio source.
2. Make sure the car stereo source mode is switched to ‘AUX’ mode.
3. Set the Transceiver unit in pairing mode. Please refer “Activating
Bluetooth
®
Transceiver pairing mode” on page 17.
4. Set the Transmitter unit in pairing mode.
5. Music starts automatically upon successful pairing.
Notes:
• You do not have to enter a dedicated pin code for pairing these two devices, as
you do with a mobile phone.
• During pairing mode, the Transceiver unit should show a slower alternate red/blue
LED. Make sure that the Transmitter and Transceiver are not paired to any other
Transceiver or Transmitter respectively.
• Please refer “Understanding The Transceiver Unit Indicators” on page 16 for
further details.
4. INTRODUCTION TO
BLUETOOTH
®
“PAIRING”
