BLT370
CAUTION
!
• The Transceiver unit can only pair and connect to ONE mobile phone at a
time.
• In order to pair and connect to another mobile phone, user will have to disconnect
the current mobile phone first. Please refer your mobile phone owner’s manual
for disconnecting device.
• The Transceiver unit can pair with the Transmitter unit and mobile phone at
the same time as long as both device (Transmitter and mobile phone) do not
use the same profiles (A2DP and AVRCP), which are used for music streaming
purposes at the same time.
4. INTRODUCTION TO
BLUETOOTH
®
“PAIRING”
Between
Bluetooth
®
Audio/Mobile-phone Transceiver and mobile
phone
1. Activate
Bluetooth
®
on your mobile phone. Please check your mobile phone
owner’s manual for further details.
2. Set the Transceiver in pairing mode. Please refer “Activating
Bluetooth
®
Transceiver pairing mode” on page 17.
3. Search for new
Bluetooth
®
device on the mobile phone. The Transceiver
unit’s name is “CLARION_HSF”.
4. When attempting to connect to the Transceiver unit, the mobile phone will
prompt for a passkey, enter the PIN: “0000”.
5. Incoming call will be automatically diverted to the Transceiver unit upon
successful connection.
Notes:
• Always make sure the
Bluetooth
®
operation mode in the phone is on when using
a
Bluetooth
®
car handsfree.
• During music streaming, pairing with mobile phone at the same time may cause
choppy sound.
1EN_OM_Receiver BLT370.indd 12 8/15/07 3:10:35 PM
