Dakota Ultrasonics
28
Note: Communications software packages generally have the ability
to capture the screen data to a common text file. This text file,
containing the measurements, can then be imported into any
common spreadsheet program (i.e. Excel, Quattro Pro,
Lotus123) for further reporting requirements.
Using The Data Logger
The MMX-6 DL is equipped with an on board data logging feature.
This will prove to be a valuable reporting tool for inspection
purposes. It will increase efficiency by reducing the time it takes to
manually record the measurements during the inspection process.
The MMX-6 DL can then be connected to a computer or serial
printer to save and print the results of the inspection.
The MMX-6 DL has a storage capacity of 1000 measurements.
The MMX-6 DL has 10 files consisting of 100 sequential
storage locations in each file. The procedure for using the data
logger is outlined in the following steps:
1) Press ON/OFF key to power up the MMX-6 DL.
2) Press the MEM key to activate the data logger.
Note:
•
The display will flash FILE / F-01 (or the last file used) symbol.
Remember, there are 10 files F-01 thru F-10.
3) Press the SEND key to enter file setup.
