Humminbird 500 Fish Finder User Manual



52
Triplog Reset
(with Temp/Speed only)
Triplog Reset resets the Triplog to zero, and will
appear in the menu if a Temp/Speed Accessory is connected and the
paddlewheel has moved at least once. The Triplog provides the following
information: timer for elapsed time, distance traveled since last reset, and
average speed.
NOTE: See Setup Menu Tab: Select Readouts (Advanced) to find out how to display
Triplog information on the screen.
To Reset Triplog:
1. Highlight Reset Triplog on the Setup menu.
2. Use the RIGHT 4-WAY Cursor Control key to initiate Triplog Reset.
3. The Confirm dialog box will appear. To reset the Triplog, press the
RIGHT Cursor key once more. To cancel Reset Triplog, press the LEFT
Cursor key.
Restore Defaults
Restore Defaults resets ALL menu settings to their
factory defaults. Use this menu choice with caution!
T
o Restore Defaults:
1. Highlight Restore Defaults on the Setup menu.
2. Use the RIGHT 4-WAY Cursor Control key to initiate restoring defaults.
3. The Confirm dialog box will appear. To reset the defaults, press the
RIGHT Cursor key once more. To cancel Restore Defaults, press the
LEFT Cursor key.
