61
Specifications
Depth Capability .............................................................. 800 ft (250 m)
Power Output .................. 250 Watts (RMS), 2000 Watts (Peak to Peak)
Operating Frequency ............ 200 kHz Single Beam (515, 525 and 535)
200 kHz and 83 kHz Dual Beam™ (565 only)
200 kHz/83 kHz/455 kHz QuadraBeam PLUS™ (575 only)
Area of Coverage................ 60° @ -10 dB in 83 kHz (565 and 575 only)
20° @ -10 dB in 200 kHz
90°Total Coverage @ -10 dB in 455 kHz (575 only)
Target Separation ................................................ 2 ¹⁄₂ Inches (63.5 mm)
Power Requirement .............................................................. 10-20 VDC
LCD Matrix .............................................................. 240 V x 160 H (515)
240 V x 240 H (525)
320 V x 320 H (535)
640 V x 320 H (565 and 575)
Transducer...................................... XHS 9 20 T (515, 525, 535 and 565)
XT 6 TB 90 T (575 only)
Transducer Cable Length ...................................................... 20 ft (6 m)
Current Draw.................................................................................. 175 mA (515)
200 mA (525 and 535)
225 mA (565 and 575)
NOTE: Humminbird® verifies maximum stated depth in saltwater conditions, but actual depth
performance may vary due to transducer installation, water type, thermal layers, bottom
composition and slope.
Product specifications and features are subject to change without notice.
