Specifications
Depth Capability . . . . . . . . . . . . . . . . . . . . . . . . 1000 ft (330 m) (717)
1500 ft (450 m) (727)
Power Output . . 300 Watts (RMS), 2400 Watts (Peak to Peak) (717)
Watts (RMS), 4000 Watts (Peak to Peak) (727)
Operating Frequency . . . . . . 200 kHz and 83 kHz DualBeam PLUS™
Area of Coverage . . . . . . . . . . . . . . . . . . . . . 60° @ -10 dB in 83 kHz
20° @ -10 dB in 200 kHz
Target Separation . . . . . . . . . . . . . . . . . . . . . . 2 ½ Inches (63.5 mm)
Power Requirement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-20 VDC
LCD Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 320V x 320H (717)
640 V x 320 H (727)
Transducer . . . . . . . . . . . . . . . . . . . . . . . . . XHS 9 20 T or XNT 9 20 T
Transducer Cable Length. . . . . . . . . . . . . . . . . . . . . . . . . . 20 ft (6 m)
Current Draw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250 mA (717)
350 mA (727)
NOTE: Humminbird® verifies maximum stated depth in saltwater conditions, but actual depth
performance may vary due to transducer installation, water type, thermal layers, bottom
composition and slope.
NOTE: Product specifications and features are subject to change without notice.
